Miele DAH4970 90cm Wide Wall Mounted Hood - A++ Rated

Seen it cheaper?
Give us a call 01737 240403

Experience unparalleled kitchen convenience with the Miele DAH4970, a 90cm wide wall mounted hood crafted in stylish Sienna Bronze or Concrete. This energy-efficient model boasts a high-performance motor that delivers a robust air throughput of up to 875 m³/h, while maintaining a low noise level between 38 dB and 68 dB depending on the level of extraction required. Featuring SmartControl technology, three speeds plus 2 booster settings, and a 10-ply stainless steel grease filter, it efficiently minimises cooking odours and fumes. Suitable for both air extraction and recirculation, the DAH4970 integrates seamlessly into any modern kitchen, enhancing both functionality and design.

Brand Miele
DAH4970 Alt Codes

EAN: Cono - 4002516802914
EAN: Pabo - 4002516802921

Colour Various Colours
Warranty 2 Years
kWh per annum 28 Estimate running costs Estimate costs
Approx. £8.4 per year
Dimensions W: 898mm x H: 420mm x D: 381mm
Release Date March 2024
A ++
Energy Rating
View Energy Label
50 dB
Noise Level
Boost Extraction Rate

Miele 90cm Wide Wall Mounted Angled Hood - Sienna Concrete / Sienna Bronze

Key Information

  • 3 Speeds and a Booster Power Level
  • Maximum Extraction Rate (Normal Use): 415 M³/H
  • Maximum Extraction Rate (Using Booster): 875 M³/H
  • Maximum Noise Level (Normal Use): 50 dB
  • Maximum Noise Level (Using Booster): 68 dB
  • Airflow Range: 215-875 M³/H
  • Noise Level Range: 38-68 dB
  • Suitable For Air Extraction Or Recirculation Mode


  • Motor: ECO motor provides high air throughput with minimal sound emissions.
  • Controls: SmartControl technology, touch-on-glass controls, and electronic controls with three power levels and a booster function.
  • Filtration: Equipped with a 10-ply stainless steel grease filter and optional DKF 29 charcoal filter for odor absorption.
  • Design: Features a stylish bronze patina color and a unique front panel design.
  • Energy Efficiency: Rated A++ for energy efficiency, minimizing environmental impact while reducing operating costs.
  • Lighting: Integrated LED lighting (1 x 3.2 W) with a light intensity of 260 lx and a color temperature of 3500 Kelvin, including a dimmer function.


  • Air Throughput: Delivers performance across multiple levels with maximum air throughput reaching up to 875 m³/h in booster level 2.
  • Sound Levels: Operates at a noise level starting from 38 dB(A) in Level 1 to a maximum of 68 dB(A) in Booster level 2, ensuring minimal disruption.

Convenience Features

  • Grease Filter Indicator: Programmable indicator to signal when the grease filter needs cleaning.
  • Run-On Time: Adjustable run-on time (5/15 minutes) to clear residual fumes after cooking.
  • Safety Features: Includes safety switch-off and single-ply safety glass (ESG).

Technical Specifications

  • Dimensions: Canopy width is 898 mm, with an overall height adjustable between 830 mm and 1210 mm for extraction mode.
  • Installation: Compatible with both ducted and recirculation installations. Exhaust connection options at the top or rear.
  • Weight: Net weight of the unit is 18 kg.

Additional Information

  • Bronze EAN: 4002516802921
  • Concrete EAN: 4002516802914
  • Material Number: 12545680
  • Old Material Number: 28H4970PGB
  • Voltage/Frequency: 230 V, 50 Hz
  • Fuse Rating: 10 A
Discover the sophistication and advanced functionality of the Miele DAH4970, a 90cm wide wall mounted hood designed to enhance any modern kitchen with its elegant Sienna Bronze finish. Engineered to provide optimal air purification, this hood offers three speed settings plus an additional booster power level, achieving maximum extraction rates of up to 875 m³/h for intensive use, while maintaining a comfortable noise level from a quiet 38 dB to 68 dB on booster mode.

This model excels in efficiency with its ECO motor, which ensures high air throughput with minimal sound emissions, making it ideal for open-plan living spaces. The DAH4970 is equipped with advanced SmartControl technology, including touch-on-glass and electronic controls, allowing for effortless operation and integration with your cooking routine. Its 10-ply stainless steel grease filter, coupled with an optional DKF 29 charcoal filter, effectively traps grease and neutralizes odours, promoting a cleaner kitchen environment.

The DAH4970 is not only powerful but also energy conscious, boasting an A++ energy rating which reduces both environmental impact and operating costs. Its sleek design features integrated LED lighting with a dimmer function to create the perfect ambience in your cooking area.

Suitable for both air extraction and recirculation setups, the DAH4970 comes with flexible installation options and safety features like a safety switch-off and single-ply safety glass. Its dimensions and design ensure it fits seamlessly above your cooktop, providing both functional and visual enhancements to your home.
